General
Device Type
Switch - 8 ports - L2+ - smart
Enclosure Type
Desktop, wall-mountable
Subtype
2.5 Gigabit Ethernet
Ports
8 x 100/1000/2.5G (PoE+) + 2 x 10Gb Ethernet SFP+
Power Over Ethernet (PoE)
PoE+
PoE Budget
160 W
Performance
Switching capacity: 80 Gbps ¦ Packet forwarding rate: 59.52 Mpps ¦ Packet buffer size: 12 Mbit
Capacity
Priority queues: 8 ¦ IPv6 interfaces: 32 ¦ IPv4 interfaces: 32 ¦ Multicast groups: 511 ¦ IP multicast profiles: 256 ¦ IP multicast entries: 16 ¦ VLAN groups: 4000 ¦ MAC VLAN address entries: 12 ¦ Access control entries: 320 ¦ IPv6 MAC port binding entries: 512 ¦ IP source guard entries: 253 ¦ IPv6 source guard entries: 183 ¦ MAC addresses per port: 64
MAC Address Table Size
16K entries
Jumbo Frame Support
9KB
Routing Protocol
Static IP routing, MLD, IGMP
Remote Management Protocol
IPv4, IPv6, HTTPS, CLI, SSH, SSH-2, DHCP, TCP/IP, UDP, Telnet, SNMP, HTTP, TFTP, MIB, RADIUS, RMON, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3
Encryption Algorithm
SSL 3.0, TLS 1.2
Authentication Method
PAP, EAP-MD5, RADIUS, Secure Shell (SSH), Secure Shell v.2 (SSH2)
Features
Fanless, cloud managed, reset button, security lock slot (cable lock sold separately), CoS, DSCP prioritisation, scheduler, QoS, SP, WRR, bandwidth control, rate limit, Storm Control, Broadcast Storm Control, Multicast Storm Control, Unknown Storm Control, DHCP server, DHCP relay, Link Aggregation, ARP support, proxy ARP, loopback detection, flow control, port mirroring, DLDP support, LLDP-MED, IGMP snooping, MVR, Multicast filtering function, device discovery, firmware upgradable, schedule reboot, network monitoring, VLAN support, GVRP, Voice VLAN, ACL support, IPMB, AAA, port isolation, dynamic IP mode, DoS attack prevention, ARP inspection, DHCP snooping, Guest VLAN, ND snooping, ND detection, Cable Diagnostics Function, EEE, SNTP support, system log, ZTP
Compliant Standards
IEEE 802.3at, IEEE 802.3af, IEEE 802.1p, IEEE 802.3x, IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.1x
Status Indicators
Power, system, link/activity, SFP+, PoE max
