Transcend MSA452T2 - SSD - 64 GB - internal - mSATA - SATA 6Gb/s
Manufacture#: TS64GMSA452T2
Checking delivery…
Payment options available at checkout
Main features
Transcend MSA452T2
SSD
64 GB
internal
mSATA
SATA 6Gb/s
Overview
Featuring the Serial ATA interface and built around a powerful controller, Transcend's SATA III 6Gb/s MSA452T2 mSATA SSD delivers blazing-fast performance. The MSA452T2 features the latest 3D NAND technology for high storage efficiency, 30µ" PCB gold finger and Corner Bond technology for enhanced durability, built-in DRAM cache for fast access, an extended operating temperature range from -20°C to 75°C, and an endurance rating of 3K Program/Erase cycles for reliable operation. The compact mSATA form factor is just one-eighth the size of a standard 2.5" SSD, making it perfect for use in space-constricted portable devices such as Ultrabooks, tablet PCs, and slim servers.
Product Description
Transcend MSA452T2 - SSD - 64 GB - SATA 6Gb/s
Type
Solid state drive - internal
Capacity
64 GB
NAND Flash Memory Type
3D triple-level cell (TLC)
Form Factor
mSATA
Interface
SATA 6Gb/s
Data Transfer Rate
600 MBps
Features
Advanced Garbage Collection, Error Correction Code (ECC), DRAM cache, DevSleep mode, Advanced Global Wear Leveling, Power Saving Mode, Block management, Security Command support, 3K P/E cycles (Programme/Erase cycles), Dynamic thermal throttling, Corner Bond technology, PCB gold finger, S.M.A.R.T., JEDEC MO-300
Dimensions (WxDxH)
29.85 mm x 50.8 mm x 4.85 mm
Weight
8 g
Manufacturer Warranty
3-year warranty
General
Device Type
Solid state drive - internal
Capacity
64 GB
NAND Flash Memory Type
3D triple-level cell (TLC)
Form Factor
mSATA
Interface
SATA 6Gb/s
Features
Advanced Garbage Collection, Error Correction Code (ECC), DRAM cache, DevSleep mode, Advanced Global Wear Leveling, Power Saving Mode, Block management, Security Command support, 3K P/E cycles (Programme/Erase cycles), Dynamic thermal throttling, Corner Bond technology, PCB gold finger, S.M.A.R.T., JEDEC MO-300
Width
29.85 mm
Depth
50.8 mm
Height
4.85 mm
Weight
8 g
Performance
Drive Writes Per Day (DWPD)
1.61
SSD Endurance
1760 TB
Drive Transfer Rate
600 MBps (external)
Internal Data Rate
560 MBps (read) / 520 MBps (write)
Maximum 4KB Random Write
85000 IOPS
Maximum 4KB Random Read
95000 IOPS
Reliability
MTBF
3,000,000 hours
Expansion & Connectivity
Interfaces
1 x SATA 6 Gb/s - 52 pin mini-SATA
Compatible Bay
mSATA
Power
Power Consumption
2.4 Watt (active) ¦ 0.4 Watt (sleep)
Miscellaneous
Compliant Standards
BSMI, FCC, RoHS2
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
-20 °C
Max Operating Temperature
75 °C
Min Storage Temperature
-40 °C
Max Storage Temperature
85 °C
Humidity Range Operating
5 - 95%
Shock Tolerance (operating)
1500 g @ 0.5 ms
Vibration Tolerance (operating)
20 g @ 7-2000 Hz
