Transcend MTS552T2 - SSD - 64 GB - internal - M.2 2242 - SATA 6Gb/s
Manufacture#: TS64GMTS552T2
Checking delivery…
Product details
SSD
64 GB
internal
M.2 2242
Payment options available at checkout
Main features
Transcend MTS552T2
SSD
64 GB
internal
M.2 2242
SATA 6Gb/s
Overview
Transcend's MTS552T2 M.2 SSD features the SATA III 6Gb/s interface, delivering superior transfer speeds. The MTS552T2 features the 3D NAND technology for high storage efficiency, 30µ" PCB gold finger and Corner Bond technology for enhanced durability, built-in DRAM cache for fast access, an extended operating temperature range from -20°C to 75°C, and an endurance rating of 3K program/erase cycles for reliable operation.
Product Description
Transcend MTS552T2 - SSD - 64 GB - SATA 6Gb/s
Type
Solid state drive - internal
Capacity
64 GB
NAND Flash Memory Type
3D triple-level cell (TLC)
Form Factor
M.2 2242
Interface
SATA 6Gb/s
Data Transfer Rate
600 MBps
Features
Native Command Queuing (NCQ), TRIM support, Advanced Garbage Collection, DDR3 DRAM Cache, Advanced Global Wear Leveling, 3D NAND Technology, ECC Recovery LDPC, Dynamic thermal throttling, S.M.A.R.T.
Dimensions (WxDxH)
22 mm x 42 mm x 3.58 mm
Weight
5 g
Manufacturer Warranty
3-year warranty
General
Device Type
Solid state drive - internal
Capacity
64 GB
NAND Flash Memory Type
3D triple-level cell (TLC)
Form Factor
M.2 2242
Interface
SATA 6Gb/s
Features
Native Command Queuing (NCQ), TRIM support, Advanced Garbage Collection, DDR3 DRAM Cache, Advanced Global Wear Leveling, 3D NAND Technology, ECC Recovery LDPC, Dynamic thermal throttling, S.M.A.R.T.
Width
22 mm
Depth
42 mm
Height
3.58 mm
Weight
5 g
Performance
Drive Writes Per Day (DWPD)
1.61
SSD Endurance
880 TB
Drive Transfer Rate
600 MBps (external)
Internal Data Rate
560 MBps (read) / 510 MBps (write)
Maximum 4KB Random Write
85000 IOPS
Maximum 4KB Random Read
85000 IOPS
Reliability
MTBF
3,000,000 hours
Expansion & Connectivity
Interfaces
1 x SATA 6 Gb/s - M.2 Card
Compatible Bay
M.2 2242
Power
Power Consumption
1.7 Watt (active) ¦ 0.3 Watt (standby)
Miscellaneous
Compliant Standards
BSMI, FCC, RoHS2
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
-20 °C
Max Operating Temperature
75 °C
Min Storage Temperature
-40 °C
Max Storage Temperature
85 °C
Humidity Range Operating
5 - 95%
Shock Tolerance (operating)
1500 g @ 0.5 ms
Vibration Tolerance (operating)
20 g @ 7-2000 Hz
