Transcend MTS570T - SSD - 128 GB - internal - M.2 2242 (double-sided) - SATA 6Gb/s
Manufacture#: TS128GMTS570T
Checking delivery…
Product details
SSD
128 GB
internal
M.2 2242 (double-sided)
Payment options available at checkout
Main features
Transcend MTS570T
SSD
128 GB
internal
M.2 2242 (double-sided)
SATA 6Gb/s
Overview
Transcend's M.2 SSD MTS570T features the SATA III 6 Gb/s interface and the state-of-the-art 3D NAND technology, which allows 112 layers of 3D NAND flash chips to be vertically stacked. Compared to 3D NAND at 96 layers, this density breakthrough greatly improves storage efficiency, and its built-in DRAM cache allows faster access. Applied with 30µ" gold finger PCB and Corner Bond technology, the MTS570T is fully tested in-house to guarantee reliability in mission-critical applications, boasting an endurance rating of 3K Program/Erase cycles and an extended operating temperature ranging from -20℃ - 75℃.
Product Description
Transcend MTS570T - SSD - 128 GB - SATA 6Gb/s
Type
Solid state drive - internal
Capacity
128 GB
NAND Flash Memory Type
3D multi-level cell (MLC)
Form Factor
M.2 2242 (double-sided)
Interface
SATA 6Gb/s
Data Transfer Rate
600 MBps
Features
Native Command Queuing (NCQ), TRIM support, Garbage Collection technology, thermal sensor, wear-resistant, Bad Block Management, Power Shield, Wide Temperature, Dynamic thermal throttling, PCB gold finger, Read Disturbance, Early Move technology, 112-layer 3D NAND technology, Anti-sulfur technology, S.M.A.R.T.
Dimensions (WxDxH)
42 mm x 22 mm x 3.58 mm
Weight
5 g
Manufacturer Warranty
3-year warranty
General
Device Type
Solid state drive - internal
Capacity
128 GB
NAND Flash Memory Type
3D multi-level cell (MLC)
Form Factor
M.2 2242 (double-sided)
Interface
SATA 6Gb/s
Features
Native Command Queuing (NCQ), TRIM support, Garbage Collection technology, thermal sensor, wear-resistant, Bad Block Management, Power Shield, Wide Temperature, Dynamic thermal throttling, PCB gold finger, Read Disturbance, Early Move technology, 112-layer 3D NAND technology, Anti-sulfur technology, S.M.A.R.T.
Width
42 mm
Depth
22 mm
Height
3.58 mm
Weight
5 g
Performance
Drive Writes Per Day (DWPD)
2.16
SSD Endurance
2420 TB
Drive Transfer Rate
600 MBps (external)
Internal Data Rate
560 MBps (read) / 520 MBps (write)
4KB Random Read
90000 IOPS
4KB Random Write
85000 IOPS
Reliability
MTBF
3,000,000 hours
Expansion & Connectivity
Interfaces
1 x SATA 6 Gb/s - M.2 B+M Key
Compatible Bay
M.2 2242 (double-sided)
Power
Power Consumption
4.5 Watt (active) ¦ 1.1 Watt (sleep)
Miscellaneous
Compliant Standards
BSMI, FCC, RoHS2, UKCA
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
-20 °C
Max Operating Temperature
75 °C
Min Storage Temperature
-55 °C
Max Storage Temperature
85 °C
Humidity Range Operating
5 - 95%
Shock Tolerance (operating)
1500 g @ 0.5 ms
Vibration Tolerance (operating)
20 g @ 7-2000 Hz
