CISCO

Cisco UCS Virtual Interface Card 1457 - network adapter - PCIe 3.0 x16 - 10Gb Ethernet / 25Gb Ethernet SFP28 x 4

Name: Cisco UCS Virtual Interface Card 1457 - network adapter - PCIe 3.0 x16 - 10Gb Ethernet / 25Gb Ethernet SFP28 x 4
Brand: CISCO
SKU: 1TNETRNE-009263
Price: 1214.77 GBP
Availability: OutOfStock

SKU

1TNETRNE-009263

Manufacture#: UCSC-MLOM-C25Q-04=

£1012.31

£1214.77 inc VAT

Checking delivery…

Product details

Network adapter
PCIe 3.0 x16
10Gb Ethernet / 25Gb Ethernet SFP28 x 4
for UCS C240 M5, SmartPlay Select C220 M5SX, SmartPlay Select C240 M5SX

View full product specification

Notify me when this product is in stock

Payment options available at checkout

Compare product

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Overview

Main features

Cisco UCS Virtual Interface Card 1457
Network adapter
PCIe 3.0 x16
10Gb Ethernet / 25Gb Ethernet SFP28 x 4
for UCS C240 M5, SmartPlay Select C220 M5SX, SmartPlay Select C240 M5SX

Overview

The Cisco UCS VIC 1457 (Figure 5) is a quad-port Small Form-Factor Pluggable (SFP28) mLOM card designed for the M5 generation of Cisco UCS C-Series Rack Servers. The card supports 10/25-Gbps Ethernet or FCoE. The card can present PCIe standards-compliant interfaces to the host, and these can be dynamically configured as either NICs or HBAs.

Specification

Product Description Cisco UCS Virtual Interface Card 1457 - network adapter - PCIe 3.0 x16 - 10Gb Ethernet / 25Gb Ethernet SFP28 x 4

Device Type Network adapter

Form Factor Plug-in module

Interface (Bus) Type PCI Express 3.0 x16

Ports 10Gb Ethernet / 25Gb Ethernet SFP28 x 4

Data Link Protocol 10GbE, 25GbE

Designed For UCS C220 M5, C220 M5SN, C220 M5SX, C240 M5, SmartPlay Select C220 M5, SmartPlay Select C220 M5S, SmartPlay Select C220 M5SX, SmartPlay Select C240 M5, SmartPlay Select C240 M5L, SmartPlay Select C240 M5SX

General

Device Type Network adapter

Form Factor Plug-in module

Interface (Bus) Type PCI Express 3.0 x16

Networking

Ports 10Gb Ethernet / 25Gb Ethernet SFP28 x 4

Connectivity Technology Wired

Data Link Protocol 10 Gigabit Ethernet, 25 Gigabit Ethernet

Expansion / Connectivity

Interfaces 4 x 10Gb Ethernet/25Gb Ethernet - SFP28

Compatibility Information

Designed For Cisco UCS C220 M5 Server (Large Form Factor Disk Drive Model), C220 M5SN SFF, C220 M5SX SFF, C240 M5 LFF Rack Server, C240 M5 LFF Rack Server (Tracer), C240 M5 Rack Server for Microsoft Azure Stack, C240 M5 SFF Rack Server, SmartPlay Select C220 M5 High Core 1, SmartPlay Select C220 M5 Standard 1, SmartPlay Select C220 M5 Standard 2, SmartPlay Select C220 M5S Basic 1 (Tracer), SmartPlay Select C220 M5S Standard 1, SmartPlay Select C220 M5S Standard 1 (Tracer), SmartPlay Select C220 M5SX, SmartPlay Select C220 M5SX (Tracer), SmartPlay Select C220 M5SX Advanced 1, SmartPlay Select C220 M5SX Advanced 1 (Tracer), SmartPlay Select C220 M5SX Advanced 2, SmartPlay Select C220 M5SX Advanced 2 (Tracer), SmartPlay Select C220 M5SX Advanced 3, SmartPlay Select C220 M5SX Advanced 4, SmartPlay Select C220 M5SX Advanced 5, SmartPlay Select C220 M5SX Basic 1, SmartPlay Select C220 M5SX Basic 2, SmartPlay Select C220 M5SX Basic 3, SmartPlay Select C220 M5SX Basic 4, SmartPlay Select C220 M5SX Expansion Pack 2, SmartPlay Select C220 M5SX High Core 2, SmartPlay Select C220 M5SX Standard 2, SmartPlay Select C220 M5SX Standard 2 (Tracer), SmartPlay Select C220 M5SX Standard 3, SmartPlay Select C220 M5SX Standard 4, SmartPlay Select C240 M5 Advanced 2, SmartPlay Select C240 M5 Standard 1, SmartPlay Select C240 M5L High Frequency 1, SmartPlay Select C240 M5L High Frequency 2, SmartPlay Select C240 M5L Standard 1, SmartPlay Select C240 M5L Standard 2, SmartPlay Select C240 M5L Standard 3, SmartPlay Select C240 M5L Standard 4, SmartPlay Select C240 M5SX, SmartPlay Select C240 M5SX (Tracer), SmartPlay Select C240 M5SX Advanced 1, SmartPlay Select C240 M5sx Advanced 2, SmartPlay Select C240 M5SX High Frequency 2, SmartPlay Select C240 M5SX Standard 2, SmartPlay Select C240 M5SX Standard 3, SmartPlay Select C240 M5SX Standard 4, SmartPlay Select C240 M5SX Standard 5, SmartPlay Select C240 M5SX Standard 6
