DS457 USB KIT DS457-SR20004ZZWW SCANNER CBL-58926-04 USB CABLE
Manufacture#: DS457-SR4U6S02AZW
Checking delivery…
Product details
USB Kit
barcode scanner
desktop
2D imager
Payment options available at checkout
Main features
Zebra DS457-SR
USB Kit
barcode scanner
desktop
2D imager
decoded
USB
Overview
The Zebra DS457 Fixed Mount Scanner Series can help, delivering fast, high-volume hands-free scanning of virtually any barcode - including 1D, 2D and direct part marks (DPM). No matter what type of barcode is presented, or whether it is printed on paper, etched into a product or displayed on a mobile phone screen, the DS457 Series provides fast, accurate scanning in a tiny footprint that fits in the most space-constrained areas.
Product Description
Zebra DS457-SR - USB Kit - barcode scanner
Type
Barcode scanner - desktop - stationary - USB - decoded
Minimum Bar Width
5 mil
Scan Element Type
2D imager
Connectivity Technology
Wired
Dimensions (WxDxH)
6.2 cm x 5.8 cm x 2.9 cm
Weight
111 g
Manufacturer Warranty
3-year warranty
General
Type
Barcode scanner - desktop - stationary
Barcode
Interface Type
USB
Minimum Bar Width
5 mil
Scan Element Type
2D imager
Light Source Wave Length
655 nm
Scan Mode
Fixed projection
Max Working Distance
41.9 cm
Skew (Degrees)
25.7
Pitch (Degrees)
39.6
Print Contrast Signal (PCS)
25%
Decode Capability
Code 39, QR code, MaxiCode, Aztec code, UPC, Postnet, PDF417, Data Matrix, PLANET, Australian Post, Japanese Post, UK Post
TTL Decoding
Decoded
Connectivity Technology
Wired
Processor
Clock Speed
624 MHz
Expansion / Connectivity
Interfaces
1 x USB - Type A
Miscellaneous
Cables Included
1 x USB cable - external
Compliant Standards
VCCI, C-Tick, CISPR 22 Class B, EN 60950, VDE, ICES-003 Class B, FCC Part 15 B, C-ETL, RoHS, ETL, IEC 60825-1, IP54
Dimensions & Weight
Width
6.2 cm
Depth
5.8 cm
Height
2.9 cm
Weight
111 g
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years
Environmental Parameters
Min Operating Temperature
-20 °C
Max Operating Temperature
50 °C
Humidity Range Operating
0 - 95% (non-condensing)
Drop Specification
1.8 m to concrete
